The tried and tested Blumotion hinge range offers the absolute best in class soft closing cabinet hinges. With the incredible blumotion mechanism, you can decide between soft closing and not depending on the weight of your cabinet door.
The Blumotion system is fully integrated to the hinge.
- CLIP top standard hinge
- BLUMOTION
- Part Number: 71B3550
- Item Number: 08884623
- Colour/Finish: Nickel Plated
- Opening angle: 110°
- Cranking: Overlay application
- Boss assembly: screw-on
- Boss material: Steel boss
- Closing mechanism: with spring
- Side adjustment: +/- 2 mm
- Depth adjustment: + 3/- 2 mm, convenient with spiral screw
- Lifetime Guarantee provided by Blum
- 3-Dimensional Front Adjustment
- Spiral Tech Depth Adjustment
- Suitable for special applications including mitred doors
Mounting plates sold separately.
Screws not included.
| application |
standard hinge |
| Cranking |
Overlay application |
| Opening angle |
110 |
| Closing mechanism |
with spring |
| hinge variant |
With integrated BLUMOTION |
| Cover cap type |
90M2503 |
| Cover cap type |
70.1503 |
| Cover cap type |
70T3504 – boss cover cap |
| Boss material |
Steel boss |
| boss finish |
Nickel plated |
| Boss assembly |
screw-on |
| Flange width |
57 |
| Flange length |
22 |
| Flange height |
3.2 |
| diametre hinge boss drilling |
35 |
| distance between drillings |
45 |
| exccentric position of fixing holes to hinge boss hole |
9.5 |
| boss drilling depth |
13 |
| Minimum drilling distance |
3 |
| Maximum drilling distance |
7 |
| arm material |
Steel |
| arm finish |
Nickel plated |
| collision measurement (hinge arm height) |
21.5 |
| Fixed dimension / factory setting |
11 |
| Type of side adjustment |
With screw |
| Side adjustment |
+/- 2 mm |
| Type of depth adjustment |
convenient with spiral screw |
| Depth adjustment |
+ 3/- 2 mm |
| Gap |
1.5 |
| Item package |
1 piece |
| packaging |
industrial packing |
